型号：TBD0599533201A     大类别：Consumer Electronics     第2级类别：Electronics Module  -->子类别：Other Accessories   审核产品   所有审核和提问(new)  1688链接英文名称：TB6560 3A 10V-35V Stepper Motor Driver Controller Board(Green)
中文名称：TB6560 3A 10V-35V 步进电机驱动器步进电机驱动板（绿色）
颜色：Green
包装：Plastic Bag
配件：null
装箱资料：
每箱：100pcs
重量：11kgs
外箱尺寸：52cm * 32cm * 32cm
采购:Karl  编辑:Shadow(2021-10-18)  美工:Shadow


1. The working voltage is DC 10V-35V. It is recommended to use a switching power supply DC24V for power supply.
2. Using 6N137 high-speed optical coupling to ensure high speed without losing step.
3. Using Toshiba TB6560AHQ chip, there are built-in low-voltage shutdown, overheating shutdown and overcurrent protection circuits to ensure performance.
4. The rated output (max) is: +/-3A, with a vertex value of 3.5A.
5. It is suitable for two-phase/four-phase/four-wire/six-wire stepping motor with 42,57 stepping within 3A, but not suitable for stepping motor with more than 3A.
6. Automatic half-flow function.
7. Subdivision: Full step, half step, 1/8 step, 1/16 step, maximum 16 subdivision.
8. Dimensions: Width 50 x length 75 x height 35 (MM)
9. Weight: 83G
10. This module does not have any protection circuit, so you must be very careful when using it, otherwise the chip is easy to burn out.

Features in similar products:
1. The current level can be adjusted step by step to meet your multiple application requirements.
2. Automatic half flow is adjustable.
3. Using 6N137 high-speed optical coupling to ensure high speed without losing step.
4. The board printing instructions can be operated without manual.
5. Adopt thick and densely toothed radiator for good heat dissipation.


中文描述：

1. 工作电压直流10V-35V。建议使用开关电源DC24V供电。
2. 采用6N137高速光藕，保证高速不失步。
3. 采用东芝TB6560AHQ芯片，内有低压关断、过热停车及过流保护电路，保证性能。
4. 额定输出（max）为：+/-3A，峰值3.5A。
5. 适合42，57步进3A以内的两相/四相/四线/六线步进电机，不适合超过3A的步进电机。
6. 自动半流功能。
7. 细分：整步，半步，1/8步，1/16步，16细分。
8. 尺寸：宽50 x 长75 x 高35（MM）
9. 重量：83G
10. 此模块没有任何保护电路，使用时必须要很小心，否则芯片很容易烧坏。

在同类产品中的特色：
1. 电流级逐可调，满足你的多种应用需求。
2. 自动半流可调。
3. 采用6N137高速光藕，保证高速不失步。
4. 板印设置说明，不用说明书亦可操作。
5. 采用厚密齿散热器，散热良好。



搜索关键词：TB6560 Stepper Motor Driver Controller Board

OEM/ODM are Welcome! we can make Customize design and print your logo
